High Lumen Output Indoor Square LED Panel Light SMD PF 0.9 6000K Thick 11mm
00x600mm Led Ceiling Panel Lights
Product specification
I. Main Technical Parameter:
2. Rated Output Power:40W
3. Rated Input Voltage:85-265 Vac；
4. Rated Input Frequency Range:47～63Hz；
5. Power Factor:≥0.93；
6. Ra>75 Material: Pure Aluminum Lamp Size: L1197*W297*T13MM
7. Rated Initial Luminous Flux: 3400 lm；
8. Rated Color Temperature:3000-6000K
7. LED chip: 96pcs SMD5630
8. Gross weight: 3.5 kg per pcs
9. Packing size: L1370*W200*H380MM (5pcs Inside)
Product advantages
1. super slim designing
2. convenient for installing , can be both installed by hanging and surface mounted
3. high light output effiency
4. low maitance .
5. fast delivery , 2 weeks after order confirmation
.
Maintenance:
Pls don’t repair or maintain the product under condition user lack of professional person or knowledge for circuit,
especially in absence of necessary equipment, avoiding extending the damage or breaking down the important
components.
As there is high voltage circuit inside the product, during maintenance pls don’t dissemble orhand touch the PCB
under power - on condition. There is isolation protection layer on circuit board, pls don’t touch acidic materials
when you disassemble the circuit board, like sweat etc. Please use plate washer water to clean the circuit board
when there is stain or dust.
Package size
| Model | Quantity/Box | NG | WG | Box Size |
| SP-PLCE3060300 | 1pcs | 2.5 kg | 3kg | 67×34×3.4cm
|
